GP-C Small Pure Sine Wave Inverter 300W 400W 500W 600W
Input Voltage: 12/24VDC | Output Voltage: 220VAC±2% | Efficiency: ≥85% | Type: High frequency Off grid Pure sine wave inverter
1 : Inverter pure sine wave output waveform, can be carried to any type of AC equipment
2 : Pure copper with good electrical conductivity, Low consumption high efficiency
3 : Temperature controlled fan,safe & power saving
4 : Safe and reliable with built in fuse
5 : Customizable inverter voltage, power, color
GP-C Series Small Pure Sine Wave Inverter
Xindun GP-C pure sine wave inverter 300w, 400w, 500w, 600w optional, maximum power up to 3000w. Using a pure sine wave inverter will give you stable and clean energy as the AC power supply. If you want to get exactly the same power as the power station, you have to buy a pure sine wave inverter. Since most of the electrical appliances and equipment we use at home are pure AC power directly from the power station, pure sine wave inverter is the best choice.
One of the biggest advantages of pure sine wave inverter is that it can work and connect to any type of equipment you can think of. Unlike the modified sine wave inverter, the pure sine wave inverter can carry inductive loads and will not damage laser printers, battery-powered appliances, furnaces and other equipment.
300W 400W 500W 600W Pure Sine Wave Inverter Parameter
Pure Sine Wave Inverter Specification | |||||
Model : GP-C | 30112/24 | 40112/24 | 50112/24 | 60112/24 | |
Rated Power | 300W | 400W | 500W | 600W | |
Battery Voltage | DC 12V/24V | ||||
Size(L*W*Hmm) | 197*55*150 | ||||
Package Size(L*W*Hmm) | 210*80*175 | ||||
N.W.(kg) | 1 | 1 | 1 | 1 | |
G.W.(kg)(Carton Packing) | 1.5 | 1.5 | 1.5 | 1.5 | |
Input | DC input voltage range | 10.5-15VDC (single battery voltage) | |||
Voltage of the battery switched on automatically |
≥11V (single battery voltage) | ||||
Ouput | Output voltage (battery mode) | 220VAC±2% | |||
Output frequency (battery mode) | 50/60HZ±1% | ||||
Efficiency | ≥85% | ||||
Output wave form | Pure Sine Wave | ||||
Protection | Battery low voltage alarm | 9.5VDC±0.5V (single battery voltage) | |||
Battery over voltage protection | 15VDC±0.5V (single battery voltage) | ||||
Ouput undervoltage protection (Battery mode) |
≤187VAC Turn off the output | ||||
Output short circuit protection (Battery mode) |
machine shut off,battery cut off | ||||
Over power protection | 110% more than rated capacity | ||||
Temperature protection | ≥90℃ machine shut off | ||||
Protection instructions: Turn off the machine during protection and the machine will automatically return to normal after troubleshooting | |||||
Display | LED. Red light:battery fault, Green light: Normal electricity | ||||
Thermal method | Cooling fan in intelligent control | ||||
On-off | locking-type | ||||
Environment | Operating temperature | -10℃~+40℃ | |||
Storage temperature | -15℃~60℃ | ||||
Noise | ≤60dB | ||||
Highest altitude | 2000m(More than derating) | ||||
Relative humidity | 0%~95%(No condensation) | ||||
Note: All specifications are subject to change without prior notice |
Where and How to Use Small Pure Sine Wave Inverter
Compared with generators and other emergency power supplies, the GP-C small pure sine wave inverter is a compact and portable generator. This function allows you to easily take it to any place you want to go. For anyone looking for emergency power supply when camping or boating outdoors, pure sine wave inverter may be a perfect choice. If you want to provide the best portable power supply for your equipment and appliances, then this type of inverter is the way to go.
Pure Sine Wave Inveter Wiring Diagram
Samll Pure Sine Wave Inverter For Car Use
Small Pure Sine Wave Inverter Packaging
The inverter is packed with solid colored cartons, and the packing list includes: pure sine wave inverter, battery cable, operation instructions, and warranty card.
Pure Sine Wave Inverter Factory
Guangdong Xindun Power Technology Co.,Ltd was founded in 2006, mainly produce and design all kinds of pure sine wave inverters and off grid solar power system. The products are approved by CE,TUV,CCC and lSO9001 Certificattion.
We are equipped with modern test equipment and excellent production technology. Xindun company has strong technical strength, sophisticated equipment, advanced technology and complete testing means. The products are produced according to national standards with stable performance, reasonable price and reliable qualty. We are committed to building great brands and always innovating and developing new product for all our customers. Relying on high quality and excellent service, we enjoy a good reputation in China. Pure sine wave inverters are sold widely in Southeast Asia,Middle East, South America,Africa and Western Europe.
Xindun company has participated in many exhibitions in various countries, and our pure sine wave inverters are widely sold all over the world and very popular among our customers.
10000 square meter factory is specially used to produce pure sine wave inverters, which is a rare and magnificent strength in the world. Xindun factory has passed on-site verification by the world's leading inspection company.
Inverter FAQ
1.Are you a pure sine wave inverter factory?
We are a pure sine wave inverter factory in Foshan, Guangdong, China. All inverters are independently developed, produced, sold and exported.
2. What kind of appliances does your inverter can be used for?
Our pure sine wave inverter can be used for both resistive load and inductive load.
3. How many kinds of output wave form for inverters?
Two kinds. Pure sine wave and modified sine wave. Pure sine wave inverter could provide high quality AC and carry various loads, while it requires high tech and high cost. Modified sine wave inverter load poorly not carrying inductive load, but the price is moderate.
